Polymaker Fiberon PA12-CF10 Black

Latest priceUnavailable

Buy on Amazon →

Manufacturer	Polymaker
Filament type	PA12
Data sheet	Not available
Format	-
Finish	Carbon Fiber
Color	Black Available in 4 other colors →
Warranty	No info provided
Availability	API Error: 403
Image	Polymaker Fiberon PA12-CF10 Carbon Fiber Nylon Filament 1.75mm Black 0.5kg

Technical properties

CompareVisualize

Density	1.06 g/cm³	ISO 1183, GB/T 1033
Melt index	25 g/10 min	280 °C, 2.16 kg
Glass transition temperature	55 °C	DSC, 10 °C/min
Melting temperature	171 °C	DSC, 10 °C/min
Crystallization temperature	120 °C	DSC, 10 °C/min
Decomposition temperature	445.2 °C	TGA, 20 °C/min
Vicat softening temperature	170.2 °C	ISO 306, GB/T 1633
Young's modulus (X-Y)	3311.2 MPa ±134.9	ISO 527, GB/T 1040
Young's modulus (Z)	1806.6 MPa ±145.7	ISO 527, GB/T 1040
Tensile strength (X-Y)	77.4 MPa ±1.1	ISO 527, GB/T 1040
Tensile strength (Z)	52.2 MPa ±0.8	ISO 527, GB/T 1040
Elongation at break (X-Y)	4.2 % ±0.4	ISO 527, GB/T 1040
Elongation at break (Z)	5 % ±1	ISO 527, GB/T 1040
Bending modulus (X-Y)	2886.5 MPa ±144.8	ISO 178, GB/T 9341
Bending modulus (Z)	1452.8 MPa ±96.5	ISO 178, GB/T 9341
Bending strength (X-Y)	112.4 MPa ±1	ISO 178, GB/T 9341
Bending strength (Z)	69.8 MPa ±2.2	ISO 178, GB/T 9341
Notched Charpy impact strength (X-Y)	9.9 kJ/m² ±0.7	ISO 179, GB/T 1043

Characteristics

Flame retardancy

HB

Data Sheet

Print suggestions

Nozzle temp	280-300 °C
Print speed	300 mm/s
Build surface temp	40-50 °C
Drying temperature	100 °C
Drying time	10 hours
Enclosed chamber	Room temperature
Annealing temperature	100 °C
Annealing time	16 hours
Cooling fan	OFF

Product prices and availability are accurate as of the date/time indicated and are subject to change. Some content on this site is provided by Amazon. This content is subject to change or removal at any time. All other content is copyright SpoolScout.com
Last updated: 2026-10-05
